3784500
VP1-130R
VP1130R
3783182 - VP1-120-R
VP1-130R
VP1-120-RA-ZX-Z-000
VP1-130-RA-ZX-Z-000-350/25
61100336000
-----------
Max. revolution (rpm)
1900
Direction of rotation changeable
no
Delivery rate (cm3/r)
130
Direction of rotation
right
Standard drive DIN
5462
Differential pressure valve (bar)
15-40
Pressure connection
1 inch internal thread
Running fit connection (inches)
1/4 internal thread
Type
VP1-130 R
Assembly flange drive
4-hole 80x80 mm
Weight (kg)
27
Operating pressure (bar)
400
Brand
Parker
Suction connection
clamped
Max. pressure (bar)
420
Material housing
cast steel
Leakage oil connection
1/4 inch internal thread
Specification drive
shaft 8x32x36
-----------
Applications:
Cargo Cranes
Forestry Cranes
Multi-Purpose Vehicles
Refuse Vehicles
Sewage Trucks
