P001474
TXV130P001474
61100436700
---------------
Weight (kg)
29,3
Brand
Leduc
Operating pressure (bar)
365
Max. torque (Nm)
730
Max. revolution (rpm)
1900
Direction of rotation changeable
yes
Max. pressure (bar)
365
Delivery rate (cm3/r)
130
Direction of rotation
left
Direction of rotation
right
Standard drive DIN
5462
Specification drive
spline shaft B8x32x36
Assembly flange drive
4-hole 80x80 mm
Type
TXV 130
Differential pressure valve (bar)
{lt} 40
Suction connection
1 1/2 inch internal thread
Pressure connection
1 inch internal thread
Leakage oil connection
1/2 inch internal thread
Running fit connection (inches)
1/4 internal thread
Material housing
cast steel
