SJEDALO ZA KOMBI, GRAMMER CHICAGO 12V (VIDI KOJI MODELI U OPISU) CITROEN JUMPER, VW LT, VW T, PEUGEOT BOXER, IVECO, MERCEDES SPRINTER, MSG90.3C-00 - GRAMMER

1040673
MSG90.3C-00
GRAMMER CHICAGO
58100041100

--------------

S INTEGRIRANIM KOMPRESOROM

-------------

ZA KOMBIJE:

Fiat Ducato od 1995 do 2002
CITROEN JUMPER (1995-2006)
IVECO Daily od 1999 do 2002
MERCEDES BENZ Sprinter do 2002
PEUGEOT BOXER (2002-2006)
VW LT I (1975-1996)
VW LT II (1996-2006)
VW T2 (1967-1979)
VW T3 (1979-1992)
VW T4 (1990-2006)

--------------

Weight (kg)
38

Brand
Grammer

Voltage (V)
12

Track width (mm)
320

For mount EPS
no

Spring deflection (mm)
60

Material seat cover
velour

Color cover
black/blue/gray

Swivel adapter
without

Suspension
pneumatic

Height setting (mm)
60

Horizontal adjustment (mm)
210

Lumbar support
pneumatic

Air supply
integrated compressor

Position operating element
left

Position operating element
front

Backrest adjustment (°)
2-12

Width seat (mm)
480

Control lever support console
without

Usage
van driver

Additional settings
weight setting automatic

Additional settings
seat cushion inclination adjustment

Additional settings
seat cushion depth adjustment

Additional settings
shock absorber adjustable

Comfort features
insertable head restraint

Type designation
Chicago
