0511625026
0511625607
R918C03580
5001021237
R918C01914
503137209
503127209
0511625018
5006009434
1515800013
378262
AZMF-11-016UCB20PL
AZMF-11-019RCB20PG210XX
------------
Weight (kg)
3,727
Brand
Bosch-Rexroth
Operating pressure (bar)
210
Max. revolution (rpm)
3000
Max. pressure (bar)
210
Displacement (cm3/r)
16
Specification drive
shaft conical 1:5
o shaft/hub (mm)
7
Center o flange (mm)
80
o oil connection A (mm)
15
Mounting oil connection A
hole circle 35 mm M 6
o oil connection B (mm)
15
Mounting oil connection B
hole circle 35 mm M 6
Direction of rotation
left
Direction of rotation
right
Assembly flange drive
4-hole 100x72 mm M 8
Usage
fan drive
