F1-101-L
3781101
3781100 - desna
F01-101-L
Max.revolution(rpm): 2100
Direction of rotation changeable: yes
Delivery rate(cm3/r): 102.9
Direction of rotation: left
Standard drive DIN 5462
Pressure connection: G1 inch internal thread
Type: F1-101-L
Assembly flange drive: 4-hole 80x80mm
Weight(kg): 12.7
Suction connection: plugged in
Material housing: aluminum
Construction: inclined axis
Specification drive: shaft 8x32x36
