PUMPA 38cm3/r, 285/11 - MEILLER

02852001101
285/101
215/101
61102599700

------------


Assembly flange drive
4-hole 80x80 mm

Brand
Meiller

Construction form
straight

Delivery rate 1 (cm3/r)
38

Delivery rate 2 (cm3/r)
38

Direction of rotation
left
right

Direction of rotation changeable
yes

Material housing
cast steel

Max. pressure (bar)
350

Max. revolution (rpm)
2400

Operating pressure (bar)
350

Pressure connection 1
M 24x1.5 external thread

Pressure connection 2
M 24x1.5 external thread

Specification drive
shaft 8x32x36

Standard drive
DIN 5462

Suction connection
M 45x2 internal thread

Weight (kg)
20,42
