PUMPA 295/154, 52cm3/r, 26cm3/r - MEILLER

02952001154
295/154
295/154B
M00691
02952001054
MEI0295.2001.054
MEI0295.2001.154

---------

Weight (kg)
19,553

Info 1
self-priming

Brand
Meiller

Operating pressure (bar)
350

Max. revolution (rpm)
2400

Direction of rotation changeable
yes

Max. pressure (bar)
350

Direction of rotation
left

Direction of rotation
right

Standard drive DIN
5462

Material housing
cast steel

Type
295/154

Delivery rate 1 (cm3/r)
52

Delivery rate 2 (cm3/r)
26

Suction connection
M 45x2 internal thread

Pressure connection 1
M 24x1.5 external thread

Pressure connection 2
M 24x1.5 external thread

Construction form
straight

Specification drive
shaft 8x32x36

Assembly flange drive
4-hole 80x80 mm
