02762001001
276/1
slr2
Weight (kg)
19,733
Brand
Meiller
Operating pressure (bar)
350
Max. revolution (rpm)
1400
Direction of rotation changeable
no
Max. pressure (bar)
350
Delivery rate (cm3/r)
89
Direction of rotation
left
Direction of rotation
right
Standard drive DIN
5462
Material housing
cast steel
Construction form
straight
Type
276/1
Specification drive
shaft 8x32x36
Assembly flange drive
4-hole 80x80 mm
Suction connection
M 45x2 internal thread
Pressure connection
M 27x2 internal thread
