PUMPA 26cm3/r, 265/44 - MEILLER

02652001044
265/44
61102597800

-----------

Assembly flange drive
4-hole 80x80 mm

Brand
Meiller

Construction form
straight

Delivery rate 1 (cm3/r)
26

Delivery rate 2 (cm3/r)
26

Direction of rotation
left
right

Direction of rotation changeable
yes

Material housing
cast steel

Max. pressure (bar)
350

Max. revolution (rpm)
2000

Operating pressure (bar)
350

Pressure connection 1
M 22x1.5 internal thread

Pressure connection 2
M 22x1.5 internal thread

Specification drive
shaft 8x32x36

Standard drive
DIN 5462

Suction connection
M 45x2 internal thread

Weight (kg)
12
