702985
SPG/01008
WGRR-06/16V
RC52305
61192599900
-------------
Connection pressure input
M 10x1 internal thread
Connection pressure output 1
M 10x1 internal thread
Connection pressure output 2
M 10x1 internal thread
Connection pressure switch
without
Height (mm)
205
Length (mm)
70
Material
aluminum
Max. operating pressure (bar)
10
Mounting method
block assembly
Number of connections pneumatic
3
Optional equipment
without
Position connection
rear
Switch position
spring centered
Weight (kg)
0,74
Width (mm)
35
With signal lamp
no
