BKH14S1011131
BKH-14S
BKH 14S 10 1113 1
M22x1,5/o14S BKH 14S 10 1113 1
62300011300
---------------
Length (mm)
33
Thread external A metric
M 22x1,5
Thread external B metric
M 22x1,5
Nominal diameter (mm)
10
Production series
heavy
For FI tube A (mm)
14
For FI tube B (mm)
14
Surface
galvanized
Type
2/2-way
Ball bore form
channel
Mounting bore (mm)
without
Width across flats square (mm)
9
Width across flats line connection (mm)
22
Material
steel
Tube AD series
14 S
Weight (kg)
0,502
Brand
Pister
Max. operating pressure (bar)
500
