HIDRAULIČNI MOTOR F1-25, 25,6cm3/r - PARKER

3781724
20100101025 - OMFB
201-001-01025
SF36634 - SUNFAB
SAM-025W-N-DL4-L35-S3G-100
61100172700

------------

Assembly flange drive
4-hole 80x80 mm

Brand
Parker

Displacement (cm3/r)
25,6

Leakage oil connection
1/2 inch internal thread

Material housing
aluminum

Max. pressure (bar)
350

Max. revolution (rpm)
3000

Max. torque (Nm)
142

Oil connection A
3/4 inch internal thread

Oil connection B
3/4 inch internal thread

Operating pressure (bar)
250

Power (kW)
20

Specification drive
shaft 8x32x36

Type
F1-25

Weight (kg)
8,5

o shaft/hub (mm)
34,9
