F01041L
3781041
F1-41-L
40,9CM3/OBR, MAX 350bar, LEFT
F01-041-L
F01041R, F01-041-R OKRENUTI
EP1398A
F01041L
42331 SCHWARZMULLER
HDS-47108-015-04742
BI40M
EX752045031
EX752045032
FOX 47
201FX047SSE
201FX0 FR 40
5041206
5041106
SC047
XP41
0517650
35204531
35204532
270/45 0270 2001 045
02702001045
HK PBA 040 L 80 51 SF HK PBA 050 L 80 51 SF
KFA2FO45/62L-DEK64
KFA2FO45/62L-MEK64
KFA2FO45/62R-DEK64
KFA2FO45/62L-MEK64
60100110479
10801504742
108-015-04742 obsolete, replaced by PM60100110479
---------------------------
Max. revolution (rpm)
2550
Direction of rotation changeable
yes
Delivery rate (cm3/r)
40,9
Direction of rotation
left
Standard drive DIN
5462
Pressure connection
G 3/4 inch internal thread
Type
F1-41-L
Assembly flange drive
4-hole 80x80 mm
Weight (kg)
8,88
Operating pressure (bar)
350
Brand
Parker
Suction connection
plugged in
Max. pressure (bar)
400
Material housing
aluminum
Construction
inclined axis
Specification drive
shaft 8x32x36
--------------------
201FX047DSE, 201FX047SSE, SCP047 20281 R 20289 R, SAP040 23040 23040R
SAP047 23047 23047R, ABER BI40M, ABER BI50M,
A17FO045/10NLWK0E81-0, R902162392,
Parker F1-41-L 3781041, F1-41-R 3784040
OMFB HDS47, 60100110473, 60100110479, HydroLeduc Xpi41 0523780,
HydroLeduc Xpi50 0523770, 14569000, 14569001, 14569016, 14569017
desno SCP-040R-N-DL4-L35-S0S-000
lijevo SCP-040L-N-DL4-L35-S0S-000
desno SCP-040R-N-DL4-H35- S0S-000
lijevo SCP-040L-N-DL4-H35-S0S-000
A17FO45/10NRWK0E81-0
HDS47SISO108-015-04742/601-001-10479
BI40M
EX752045031
EX752045032
FOX 47 201FX047SSE 201FX0 FR 40
5041206
5041106 SC 047 XP41
0517650
35204531
35204532
270/45 0270 2001 045
02702001045 HK PBA 040 L 80 51 SF HK PBA 050 L 80 51 SF
KFA2FO45/62L-DEK64
KFA2FO45/62L-MEK64
KFA2FO45/62R-DEK64
KFA2FO45/62L-MEK64
DP066189
HDS47 L PTO/4
10801504742
60100110479
