02952001016
295/16
61102597200
-----------
with intermediate flange 85 mm for ZF gearbox with auxiliary drive N71/1c
Assembly flange drive
4-hole 80x80 mm
Brand
Meiller
Construction form
straight
Delivery rate (cm3/r)
78
Direction of rotation
left
right
Direction of rotation changeable
no
Info 1
intermediate flange 85 mm
Material housing
cast steel
Max. pressure (bar)
350
Max. revolution (rpm)
1800
Operating pressure (bar)
350
Pressure connection
M 27x2 internal thread
Specification drive
shaft 8x32x36
Standard drive
DIN 5462
Suction connection
M 45x2 internal thread
Weight (kg)
21,2
