3780772
F12-080
Max. torque (Nm)
127,6
Max. revolution (rpm)
4800
Displacement (cm3/r)
80,4
Oil connection A
1 inch SAE 6000
Oil connection B
1 inch SAE 6000
Max. oil flow (l/min)
386
Type
F12-080
Assembly flange drive
4-hole 127x127 mm
Weight (kg)
26
Operating pressure (bar)
420
Brand
Parker
o shaft/hub (mm)
40
Max. pressure (bar)
480
Material housing
cast steel
Leakage oil connection
M 22x1.5 internal thread
Specification drive
shaft cylindrical (metric) with feather key
