DISTRIBUTER AUTOMATSKI HIDRAULIČNI RAZDJELNIK 160 BAR, MAX 250Bar, 3/4 PTO

D140PP175PP
D130PP164HP
D130PP164HPX
61100469100

------------

Tighten the fastening screws with max. 25 Nm +/- 5 Nm!


Connection consumer
G 3/4 inch internal thread

Connection control line
push-in 6x1

Connection pressure input
3/4 inch external thread

Flow lowering operation (l/min)
140

Flow rate tilting operation (l/min)
140

Material
cast steel

Max. operating pressure (bar)
350

Set pressure (bar)
175

Surface
galvanized

Test connection
1/8 inch internal thread

Type
DM140

Weight (kg)
5,305
